high capacity Double head ABA Three layers Co-extrusion Film blowing machine

China high capacity Double head  ABA Three layers Co-extrusion  Film blowing machine supplier
high capacity Double head  ABA Three layers Co-extrusion  Film blowing machine supplier high capacity Double head  ABA Three layers Co-extrusion  Film blowing machine supplier high capacity Double head  ABA Three layers Co-extrusion  Film blowing machine supplier high capacity Double head  ABA Three layers Co-extrusion  Film blowing machine supplier high capacity Double head  ABA Three layers Co-extrusion  Film blowing machine supplier

Large Image :  high capacity Double head ABA Three layers Co-extrusion Film blowing machine

Product Details:

Place of Origin: CHINA
Brand Name: SANBI
Certification: CE, ISO9001
Model Number: SJABA 600 / SJ-ABA800

Payment & Shipping Terms:

Minimum Order Quantity: 1 sets
Price: 40000-50000USD
Packaging Details: wooden package
Delivery Time: within 30 workdays
Payment Terms: T/T, L/C, Western Union, MoneyGram
Supply Ability: 30 sets of month
Detailed Product Description
Material: HDPE,.LDPE. CACO3 Screws: Double Layers Co-extrusion Screw
Capacity: 60-80kgs Head Model: ABA Double Head
Rewinder: Automatic Rewinder Certificate: CE
High Light:

Plastic Film Blowing Machine

,

High Speed Film Blowing Machine

CE Double head  ABA Three layers Co-extrusion  Film blowing machine


Quick Detail:
3 Layers Co-extrusion Film Blowing Machine
1. ABA Three layers  double die head
2.  automatic double rewinder
3. mix CaCo3 save PE material
4. high capacity .  cheaper than ABC type three layers machine


Condition

New

Application

Film

Plastic Processed

pe

Blow Moulding Type

Extrusion Blow Moulding

Automatic

Yes

Place of Origin

Zhejiang, China (Mainland)

Brand Name

SANBI

Model Number

SJ-55X55FM650

Material

LDPE,HDPE, Can mix CaCo3

Layers

3 layers

Extusion

Co-extrusion

Capacity

100-120KGS

Die head

DOUBLE HEAD

Winder

AUTOMATIC REWINDER

Certificate

CE,ISO



Description:
3-layers ABA co-extrusion blowing film machine enjoys special advantages and can produce both HDPE and LDPE Film. it improve the physical toughness of film through multi-layers co-extrusion. with one main extruder providing material for outer and inner layer. it reduces one man extruder configurations and achieves energy saving and low consumption.


Applications:



The lines are designed developed by our corporation according to market need, they reach the advanced levels in the 90s, come up with analogous lines in home.
It is optimum designed on the trounds of preference of analogous lines in foreign and home.
bsp;film through multi-layers co-extrusion. with one main extruder providing material for outer and inner layer. it reduces one man extruder configurations and achieves energy saving and low consumption.



Specifications:



MODEL

ABA55X2X800X2F

FEATURE

SUITABLE MATERIAL

HDPE



LAYER NUMBER

3-ABA



FILM THICKNESS

0.008-0.05MM



MAX OUTPUT

100-140KG/H



MAX FILM WIDTH

700MM

EXTRUSION UNIT

SCREW DIAMETER

Φ55X2



SCREW L/D RATIO

 30/1



SCREW  MATERIAL

BIMETALLIC



BARREL THERMO CONTROL

6



BARREL COOLING FAN

200W



SCREEN CHANGER

LONG TYPE



DRIVING MOTOR

22KWX2

EXTRUSION DIE UNIT

DIE DIAMETER

HDABAΦ100 X 2



DIE THEROMO CONTROL

2X2



AIR RING

DOUBLE LIP



FLANGE THERMO CONTROL

2



AIR BLOWER

3.7KW X 2

TAKE-UP UNIT

TAKE-UP ROLLER LENGTH

800MM X 2



EMBOSSING ROLLER

2



GUSSET

2



TAKE-UP MOTOR

1.5KWX2



TAKE-UP SPEED

10-100M/MIN

WINDING UNIT

WINDING TYPE

SINGLE FRICTION WINDER X2



WINDING ROLLER LENGTH

500MM X 2



MAX DIA.OF WINDED ROLL

800MM



WINDING MOTOR

1.5KW



Competitive Advantage:

 high capacity Double head  ABA Three layers Co-extrusion  Film blowing machine
 high capacity Double head  ABA Three layers Co-extrusion  Film blowing machine






high capacity Double head  ABA Three layers Co-extrusion  Film blowing machine
